| Combustion Temperature | ~ 1200 ℃(1800 ℃ can be reached temporarily) |
|---|
| Operating modes | CHNS, CHN, CN, N, S, O as standard with TCD
IR Detector available for sensitive S, O measurement |
|---|
| Precision | < 0.2% relSD (100 mg glutamic acid)
* depending on sample kind, analysis mode and options |
|---|
| Self-Optimizing analysis time | 10 ~ 12 min in CHNS mode
7 ~ 8 min in CHN mode
5 ~ 7 min in Oxygen mode
* depending on sample kind, analysis mode and options |
|---|
| Sample weight | Up to 1.5 g soil sample
Up to 200 mg organic sample |
|---|
| Detection range | C : 0 to 150 mg abs. ( or 100%)
N : 0 to 100 mg abs. ( or 100%)
H : 0 to 15 mg abs. ( or 100%)
S : 0 to 18 mg abs. ( or 100%)
* depending on sample kind, analysis mode and options |
|---|
| Detection limit | CN with TCD : < 50 ppm (for 300 mg soil sample)
S with IR : 10 ppm for S with IR detector (for 300 mg soil sample) |
|---|
| Autosampler | 60 positions ( optional 80 or 120)
Liquid auto sampler 장착 가능 |
|---|
| Gases | He : 99.995% purity
O2 : 99.995% purity
Argon : 헬륨가스 대체 가능 |
|---|
| Electrical connections | 100/110/200/230V, 50/60Hz, 1.8kw |
|---|
| Dimensions | 48 x 55 x 55 cm ( W x D x H ) |
|---|
| Weight | Approx.. 65 kg |
|---|
